12V-48V DC 100A Circuit Breaker Waterproof Manual Resettable Inline Fuse Holder Inverter for Electric Boat Trolling Motors

Features: 1.Manual open circuit push button. 2.No fuse change trouble. 3.Self-Testing & Manual Override. 4.instead of built-in fuse holder. 5.Easy to operate with manual reset arm. 6.Great safety and cost effectiveness. 7.Made of alloy materials, good conductivity, high technology and high temperature resistance. 8.Unique Push Button Reset can also be used as a Kill Switch. Application: Suitable for car audio/video system, Boat, trucks, buses, RV's, ATV Winches and marine and DC sound amplifier system overload protection. Specification: Power Rating: 100 Ampere Rated current: 30A/40A/50A/60A/70A/80A/100A/120A/150A/200A/250A/300A Manual Reset Circuit Breaker for choose Rated voltage: 12-48VDC Maximum Breaking capacity: 3000A @ 48 VDC Ambient temperature: -32 °C to 82 °C (-25 °F to 180 °F) Storage Temperature: -34 °C to 149 °C (-30°F to 300°F ) Water resistant housing ,splash & dust Proof Surface Mount, protective stud insulator included Size: (LxWxH) 74 x 49 x 45 mm /2.9 x 1.9 x1.7 inch Instructions: 1.Wiring IN (BAT) incoming line, OUT (AUX) outgoing line. 2.Press the ellipse button, the long handle pops open, and the breaker is powered off. (Be sure to press the ellipse button. If you use the long handle to power off the handle, the breaker will be broken.) 3.After resetting the popped long handle, the circuit breaker is energized. Package Contents: 1pcs x 100A Car Audio Circuit Breaker 2pcs x Copper Wire Terminal Lugs 4pcs x M6 Copper Washers

• 【SIZE】100 Amps Car Audio circuit breaker, use in place of an inline fuse holder. Water resistant housing, protective stud insulator included, splash & dust Proof, compatible with all 12V/48V DC Systems.
• 【FUNCTION】This circuit breaker can protect the amplifier from electrical damage, prevents excessive current or voltage stops power surges from damaging Amps. Meanwhile, the power supply can also be protected to avoid battery crack and explosion caused by short circuit.
• 【SPECIFICATION】Current 30A 40A 50A 60A 70A 80A 100A 120A 150A 200A 250A 300A waterproof circuit breaker for choose, accessories Including Copper Wire Terminal Lugs 2pcs and copper washer 4pcs, improve the conductivity.
• 【EASY To USE】Manual Reset, just press on the button and the circuit will close/open. Unique Push Button Reset can also be used as a Kill Switch. No need to disassemble the power cord and Screw terminals hold cables securely in place, can be mount on panel or firewall.
• 【APPLICATION】Typically used in solar system, battery charges, inverter, Car audio video system, boat, marine, bike, RV and DC sound amplifier system.
